Description Unique Feature ASRock Full Spike Protection ASRock APP Shop CPU – Supports Socket FM2 95W / FM2 100W processors Chipset – AMD A68H (Bolton-D2H) Memory – Dual Channel DDR3 Memory Technology – 2 x DDR3 DIMM Slots – Supports DDR3 2400 (OC) / 2133(OC) / 1866(OC) / 1600 / 1333/1066 non-ECC, un-buffered memory – Max. capacity of system memory: 32GB* – Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2 – Supports AMD Memory Profile Technology (AMP) up to AMP 2400 *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation. BIOS – 64Mb AMI UEFI Legal BIOS with GUI support – Supports “Plug and Play” – ACPI 1.1 Compliant wake up events – Supports jumperfree – SMBIOS 2.3.1 support – DRAM, CPU Voltage multi-adjustment Graphics – Integrated AMD Radeon™ R7/R5 Series Graphics in A-series APU – DirectX 11.1, Pixel Shader 5.0 with FM2 CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU. – Max. shared memory 2GB – Dual graphics output options: support DVI-D and D-Sub by independent display controllers – Supports Dual-link DVI-D with max. resolution up to 2560×1600 @ 60Hz – Supports D-Sub with max. resolution up to 1920×1200 @ 60Hz – Supports AMD Steady Video™ 2.0: New video post processing capability for automatic jitter reduction on home/online video – Supports HDCP with DVI-D Port – Supports Full HD 1080p Blu-ray (BD) playback with DVI-D Port Audio – 5.1 CH HD Audio (Realtek ALC662 Audio Codec) – Supports Surge Protection (ASRock Full Spike Protection) LAN – PCIE x1 Gigabit LAN 10/100/1000 Mb/s – Realtek RTL8111H/RTL8111GR – Supports Wake-On-LAN – Supports Lightning/ESD Protection (ASRock Full Spike Protection) – Supports Energy Efficient Ethernet 802.3az – Supports PXE Slots – 1 x PCI Express 3.0 x16 Slot (PCIE1@ x16 mode) – 1 x PCI Express 2.0 x1 Slot – 1 x PCI Slot – Supports AMD Dual Graphics *PCIE 3.0 is only supported with FM2 CPU. With FM2 CPU, it only supports PCIE 2.0. Storage – 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug Connector – 1 x Print Port Header – 1 x COM Port Header – 1 x Chassis Intrusion Header – 1 x TPM Header – 1 x CPU Fan Connector (4-pin) – 1 x Chassis Fan Connector (4-pin) – 1 x Power Fan Connector (3-pin) – 1 x 24 pin ATX Power Connector – 1 x 4 pin 12V Power Connector – 1 x Front Panel Audio Connector – 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) – 1 x Flexible USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) *This Flexible USB 2.0 header allows users to connect a Front USB 3.0 Panel, and support two USB ports with 2.0/1.1 data rate. Rear Panel I/O – 1 x PS/2 Mouse/Keyboard Port – 1 x D-Sub Port – 1 x DVI-D Port – 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)) – 2 x USB 3.1 Gen1 Ports (AMD A68H (Bolton-D2H)) (Supports ESD Protection (ASRock Full Spike Protection)) – 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) – HD Audio Jacks: Line in / Front Speaker / Microphone Software and UEFI Software – ASRock A-Tuning – ASRock Disk Health Report – ASRock USB Key – ASRock APP Charger – ASRock XFast RAM – ASRock Restart to UEFI – ASRock X-Boost UEFI – ASRock Interactive UEFI – ASRock Instant Boot – ASRock Instant Flash – ASRock Internet Flash – ASRock Crashless BIOS – ASRock OMG (Online Management Guard) – ASRock UEFI System Browser – ASRock UEFI Tech Service – ASRock Dehumidifier Function – ASRock Easy RAID Installer – ASRock Easy Driver Installer Support CD – Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar, Start8 (30 days trial) Accessories – Quick Installation Guide, Support CD, I/O Shield – 2 x SATA Data Cables Hardware Monitor – CPU temperature sensing – Chassis temperature sensing – CPU Fan Tachometer – Chassis Fan Tachometer – CPU, Chassis Quiet Fan – CPU, Chassis Fan multi-speed control – CASE OPEN detection – Voltage monitoring: 12V, 5V, 3.3V, Vcore Form Factor – Micro ATX Form Factor – All Solid Capacitor design – High Density Glass Fabric PCB OS – Microsoft Windows® 10 32-bit / 10 64-bit / 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit *Carrizo FM2r2 processor supports Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit only. Certifications – FCC, CE – ErP/EuP ready (ErP/EuP ready power supply is required)
